# Visual Test Kits

CHEMetrics visual test kits are self-contained kits that do not require any additional equipment, such as a photometer or other instrumentation, to use. This makes them cost effective as well as highly portable, fast and convenient.

CHEMetrics visual test kits comprise both Visual Colourimetric test kits (CHEMets and VACUettes) and Titrimetric test kits (Titrets) and cover virtually every water quality analyte in the CHEMetrics range. For more information on how these kits work, please see the Test Methods page. The core technology at the heart of these non-instrumental test kits is the CHEMetrics Self-Filling Reagent Ampoule. Premixed. Premeasured. Precise.

Each kit contains 30 ampoules for 30 tests. Additional refill packs of 30 ampoules are available for each CHEMets and VACUettes kit. Titrets do not employ colour comparators and are self-contained, consumable items.

Please note that the units 'ppm' are equivalent to 'mg/l'.

Analyte | Test Range | Method / Chemistry | Type | Test Kit | Refill | ||||||

Alkalinity (Hydrate) | 100 - 1,000 ppm (as NaOH) |
Acid Titrant with pH Indicator |
Titrets | K-4710 | - | ||||||

Alkalinity (Total) | 10 - 100 ppm (as CaCO _{3}) |
Acid Titrant with pH Indicator |
Titrets | K-9810 | - | ||||||

Alkalinity (Total) | 50 - 500 ppm (as CaCO _{3}) |
Acid Titrant with pH Indicator |
Titrets | K-9815 | - | ||||||

Alkalinity (Total) | 100 - 1,000 ppm (as CaCO _{3}) |
Acid Titrant with pH Indicator |
Titrets | K-9820 | - | ||||||

Ammonia | 0 - 4 ppm & 0 - 80 ppm |
Hydroxybenzyl Alcohol (HBA) | CHEMets | K-1420 | R-1402 | ||||||

Ammonia | 0.0 - 1.0 ppm & 1 - 10 ppm (as N) |
Direct Nesslerisation | CHEMets | K-1510 | R-1501 | ||||||

Ammonia | 0 - 30 ppm & 30 - 300 ppm (as N) |
Direct Nesslerisation | VACUettes | K-1510D | R-1501D | ||||||

Ammonia | 0 - 60 ppm & 60 - 600 ppm (as N) |
Direct Nesslerisation | VACUettes | K-1510A | R-1501A | ||||||

Ammonia | 0 - 120 ppm & 120 - 1,200 ppm (as N) |
Direct Nesslerisation | VACUettes | K-1510B | R-1501B | ||||||

Ammonia | 0 - 1,000 ppm & 1,000 - 10,000 ppm (N) |
Direct Nesslerisation | VACUettes | K-1510C | R-1501C | ||||||

Bromine | 0.0 - 2.2 ppm & 0 - 11 ppm |
DPD | CHEMets | K-1605 | R-1605 | ||||||

Carbohydrazide | 0.0 - 0.5 ppm | PDTS | CHEMets | K-1805 | R-1805 | ||||||

Carbon Dioxide (Dissolved) |
10 - 100 ppm | Caustic Titrant with pH Indicator |
Titrets | K-1910 | - | ||||||

Carbon Dioxide (Dissolved) |
100 - 1,000 ppm | Caustic Titrant with pH Indicator |
Titrets | K-1920 | - | ||||||

Carbon Dioxide (Dissolved) |
250 - 2,500 ppm | Caustic Titrant with pH Indicator |
Titrets | K-1925 | - | ||||||

Chloride | 20 - 200 ppm | Mercuric Nitrate | Titrets | K-2020 | - | ||||||

Chloride | 50 - 500 ppm | Mercuric Nitrate | Titrets | K-2050 | - | ||||||

Chloride | 250 - 2,500 ppm | Mercuric Nitrate | Titrets | K-2051 | - | ||||||

Chloride | 1,000 - 10,000 ppm | Mercuric Nitrate | Titrets | K-2055 | - | ||||||

Chloride | 10,000 - 100,000 ppm | Mercuric Nitrate | Titrets | K-2070 | - | ||||||

Chlorine (Free & Total) | 0.1 - 2.0 ppm | DPD | CHEMets | K-2500 | R-2500 | ||||||

Chlorine (Free & Total) | 0.0 - 1.0 ppm & 0 - 5 ppm |
DPD | CHEMets | K-2504 | R-2500 | ||||||

Chlorine (Free & Total) | 0 - 25 ppm & 0 - 125 ppm |
DPD | CHEMets | K-2504D | R-2504 | ||||||

Chlorine (Free & Total) | 0 - 50 ppm & 0 - 250 ppm |
DPD | CHEMets | K-2504A | R-2504 | ||||||

Chlorine (Free & Total) | 0 - 100 ppm & 0 - 500 ppm |
DPD | CHEMets | K-2504B | R-2509 | ||||||

Chlorine (Free & Total) | 0 - 400 ppm & 0 - 2,000 ppm |
DPD | CHEMets | K-2504C | R-2509 | ||||||

Chlorine (Free & Total) | 0.0 - 1.0 ppm & 1 - 5 ppm |
DDPD | CHEMets | K-2505 | R-2505 | ||||||

Chlorine (Free & Total) | 0.00 - 0.20 ppm | DDPD | ULR CHEMets | K-2511 | R-2511 | ||||||

Chlorine (Hypochlorite) | 0.0 - 1.55 % (as NaOCl) |
DPD | CHEMets | K-5808 | R-5808 | ||||||

Chlorine (Hypochlorite) | 0 - 12.5 % (as NaOCl) |
DPD | CHEMets | K-5816 | R-5808 | ||||||

Chlorine Dioxide | 0.0 - 2.0 ppm & 2 - 10 ppm |
DPD | CHEMets | K-2705 | R-2705 | ||||||

Chromate (Hexavalent) | 0.0 - 1.0 ppm & 1 - 10 ppm |
Diphenylcarbazide | CHEMets | K-2810 | R-2810 | ||||||

Chromate (Hexavalent) | 0 - 30 ppm & 30 - 300 ppm |
Diphenylcarbazide | VACUettes | K-2810D | R-2810D | ||||||

Chromate (Hexavalent) | 0 - 60 ppm & 60 - 600 ppm |
Diphenylcarbazide | VACUettes | K-2810A | R-2810A | ||||||

Chromate (Hexavalent) | 0 - 120 ppm & 120 - 1,200 ppm |
Diphenylcarbazide | VACUettes | K-2810B | R-2810B | ||||||

Chromate (Hexavalent) | 0 - 1,200 ppm & 1,200 - 12,000 ppm |
Diphenylcarbazide | VACUettes | K-2810C | R-2810C | ||||||

Copper (Soluble) | 0.0 - 1.0 ppm & 1 - 10 ppm |
Bathocuproine | CHEMets | K-3510 | R-3510 | ||||||

Cyanide (Free) | 0.00 - 0.10 ppm & 0.1 - 1.0 ppm |
Isonicotinic -Barbituric Acid |
CHEMets | K-3810 | R-3810 | ||||||

DEHA | 0 - 400 ppb & 400 - 3,000 ppb |
PDTS | CHEMets | K-3902 | R-3902 | ||||||

DEHA | 25 - 250 ppm | Ceric Sulphate / Ferroin |
Titrets | K-3925 | - | ||||||

Detergents (Anionic Surfactants) |
0.0
- 3.0 ppm (as LAS) |
MBAS | CHEMets | K-9400 | R-9400 | ||||||

Detergents (Anionic Surfactants) |
0
- 1,400 ppm (as LAS) |
MBAS | CHEMets | K-9404 | R-9404 | ||||||

Filming Amines (Aliphatic Amines) |
0.0 - 1.0 ppm (as Octadecylamine) |
Methyl Orange | CHEMets | K-1001 | R-1000 | ||||||

Formaldehyde | 0.0 - 1.0 ppm & 1 - 10 ppm |
Purpald | CHEMets | K-4605 | R-4605 | ||||||

Formaldehyde | 0 - 30 ppm & 30 - 300 ppm |
Purpald | VACUettes | K-4605D | R-4605D | ||||||

Formaldehyde | 0 - 60 ppm & 60 - 600 ppm |
Purpald | VACUettes | K-4605A | R-4605A | ||||||

Formaldehyde | 0 - 120 ppm & 120 - 1,200 ppm |
Purpald | VACUettes | K-4605B | R-4605B | ||||||

Formaldehyde | 0 - 1,200 ppm & 1,200 - 12,000 ppm |
Purpald | VACUettes | K-4605C | R-4605C | ||||||

Glycol, Ethylene | 1 - 15 ppm (30,000 ppm w/dil.) |
Purpald-Periodate | CHEMets | K-4815 | R-4815 | ||||||

Hardness (Calcium) | 50 - 500 ppm (as CaCO _{3}) |
EGTA | Titrets | K-1705 | - | ||||||

Hardness (Total) | 2 - 20 ppm (as CaCO _{3}) |
EDTA | Titrets | K-4502 | - | ||||||

Hardness (Total) | 20 - 200 ppm (as CaCO _{3}) |
EDTA | Titrets | K-4520 | - | ||||||

Hardness (Total) | 100 - 1,000 ppm (as CaCO _{3}) |
EDTA | Titrets | K-4585 | - | ||||||

Hydrazine | 0.00 - 0.5 ppm | PDMAB | CHEMets | K-5005 | R-5005 | ||||||

Hydrazine | 0 - 12.5 ppm | PDMAB | VACUettes | K-5005D | R-5005D | ||||||

Hydrazine | 0 - 25 ppm | PDMAB | VACUettes | K-5005A | R-5005A | ||||||

Hydrazine | 0 - 50 ppm | PDMAB | VACUettes | K-5005B | R-5005B | ||||||

Hydrazine | 0 - 500 ppm | PDMAB | VACUettes | K-5005C | R-5005C | ||||||

Hydrazine | 0 - 50 ppb | PDMAB | ULR CHEMets | K-5011 | R-5011 | ||||||

Hydrogen Peroxide | 0.0 - 0.5 ppm | DPD | CHEMets | K-5502 | R-5502 | ||||||

Hydrogen Peroxide | 0.0 - 0.8 ppm & 1 - 10 ppm |
Ferric Thiocyanate | CHEMets | K-5510 | R-5510 | ||||||

Hydrogen Peroxide | 0 - 25 ppm & 30 - 300 ppm |
Ferric Thiocyanate | VACUettes | K-5510D | R-5510D | ||||||

Hydrogen Peroxide | 0 - 60 ppm & 60 - 600 ppm |
Ferric Thiocyanate | VACUettes | K-5510A | R-5510A | ||||||

Hydrogen Peroxide | 0 - 120 ppm & 120 - 1,200 ppm |
Ferric Thiocyanate | VACUettes | K-5510B | R-5510B | ||||||

Hydrogen Peroxide | 0 - 1,200 ppm & 1,200 - 12,000 ppm |
Ferric Thiocyanate | VACUettes | K-5510C | R-5510C | ||||||

Hydrogen Peroxide | 0.1 - 1.0 % (20% w/dilution) |
Ceric Sulphate / Ferroin |
Titrets | K-5530 | - | ||||||

Iron (Total & Soluble) | 0.0 - 1.0 ppm & 1 - 10 ppm |
Phenanthroline | CHEMets | K-6010 | R-6001 | ||||||

Iron (Total & Soluble) | 0 - 30 ppm & 30 - 300 ppm |
Phenanthroline | VACUettes | K-6010D | R-6001D | ||||||

Iron (Total & Soluble) | 0 - 60 ppm & 60 - 600 ppm |
Phenanthroline | VACUettes | K-6010A | R-6001A | ||||||

Iron (Total & Soluble) | 0 - 120 ppm & 120 - 1,200 ppm |
Phenanthroline | VACUettes | K-6010B | R-6001B | ||||||

Iron (Total & Soluble) | 0 - 1,200 ppm & 1,200 - 12,000 ppm |
Phenanthroline | VACUettes | K-6010C | R-6001C | ||||||

Iron in Brine | 0 - 100 mg/l & 100 - 1,000 mg/l |
Ferric Thiocyanate | CHEMets | K-6002 | R-6002 | ||||||

Iron (Total & Ferrous) | 0.0 - 1.0 ppm & 1 - 10 ppm |
Phenanthroline | CHEMets | K-6210 | R-6201 | ||||||

Iron (Total & Ferrous) | 0 - 30 ppm & 30 - 300 ppm |
Phenanthroline | VACUettes | K-6210D | R-6201D | ||||||

Manganese | 0.0 - 2.0 ppm | Periodate | CHEMets | K-6502 | R-6502 | ||||||

Manganese | 0 - 50 ppm | Periodate | VACUettes | K-6502D | R-6502D | ||||||

Mercaptobenzothiazole (MBT) |
50 - 500 pppm | Permanganate | Titrets | K-6810 | - | ||||||

Molybdate | 0 - 7 ppm (as Mo) | Catechol | CHEMets | K-6701 | R-6702 | ||||||

Molybdate | 2 - 24 ppm (as Mo) | Catechol | CHEMets | K-6702 | R-6702 | ||||||

Molybdate | 20 - 200 ppm (as Mo) | Catechol | CHEMets | K-6720 | R-6720 | ||||||

Nitrate | 0.0 - 3.4 ppm (as N) | Zinc Reduction | CHEMets | K-6905 | R-6905 | ||||||

Nitrate | 0.0 - 4.5 ppm (as N) | Cadmium Reduction | CHEMets | K-6904 | R-6902 | ||||||

Nitrate | 0 - 45 ppm (as N) | Cadmium Reduction | CHEMets | K-6909D | R-6904 | ||||||

Nitrate | 0 - 225 ppm (as N) | Cadmium Reduction | CHEMets | K-6909A | R-6904 | ||||||

Nitrate | 0 - 675 ppm (as N) | Cadmium Reduction | CHEMets | K-6909B | R-6909 | ||||||

Nitrate | 0 - 2,700 ppm (as N) | Cadmium Reduction | CHEMets | K-6909C | R-6909 | ||||||

Nitrite | 0.0 - 2.5 ppm (as N) | Azo Dye Formation | CHEMets | K-7004 | R-7002 | ||||||

Nitrite | 0 - 80 ppm (as N) | Azo Dye Formation | VACUettes | K-7004D | R-7002D | ||||||

Nitrite | 0 - 170 ppm (as N) | Azo Dye Formation | VACUettes | K-7004A | R-7002A | ||||||

Nitrite | 0 - 300 ppm (as N) | Azo Dye Formation | VACUettes | K-7004B | R-7002B | ||||||

Nitrite | 0 - 3,000 ppm (as N) | Azo Dye Formation | VACUettes | K-7004C | R-7002C | ||||||

Nitrite | 250 - 2,500 ppm (as NaNO _{2}) |
Ceric Sulphate / Ferroin |
Titrets | K-7025 | - | ||||||

Nitrite | 500 - 5,000 ppm (as NaNO _{2}) |
Ceric Sulphate / Ferroin |
Titrets | K-7050 | - | ||||||

Oxygen (Dissolved) | 0.0 - 1.0 ppm | Rhodazine D | CHEMets | K-7501 | R-7501 | ||||||

Oxygen (Dissolved) | 0 - 20 ppb | Rhodazine D | ULR CHEMets | K-7511 | R-7511 | ||||||

Oxygen (Dissolved) | 1 - 12 ppm | Indigo Carmine | CHEMets | K-7512 | R-7512 | ||||||

Oxygen (Dissolved) | 5 - 180 ppb | Rhodazine D | CHEMets | K-7518 | R-7518 | ||||||

Oxygen (Dissolved) | 0 - 40 ppb | Rhodazine D | CHEMets | K-7540 | R-7540 | ||||||

Oxygen (Dissolved) | 0 - 100 ppb | Rhodazine D | CHEMets | K-7599 | R-7540 | ||||||

Ozone | 0.0 - 0.6 ppm & 0.6 - 3.0 ppm |
DPD | CHEMets | K-7404 | R-7404 | ||||||

Peracetic Acid | 0.0 - 1.0 ppm & 0 - 5 ppm |
DPD | CHEMets | K-7904 | R-7904 | ||||||

Peroxide | See Hydrogen Peroxide |
- | - | - | - | ||||||

Persulphate | 0 - 5.6 ppm & 7 - 70 ppm (Na _{2}S_{2}O_{8}) |
Ferric Thiocyanate | CHEMets | K-7870 | R-7870 | ||||||

Phenols | 0.0 - 1.0 ppm & 0 - 12 ppm |
4-Aminoantipyrine | CHEMets | K-8012 | R-8012 | ||||||

Phenols | 0 - 30 ppm & 0 - 350 ppm |
4-Aminoantipyrine | VACUettes | K-8012D | R-8012D | ||||||

Phenols | 0 - 60 ppm & 0 - 700 ppm |
4-Aminoantipyrine | VACUettes | K-8012A | R-8012A | ||||||

Phenols | 0 - 120 ppm & 0 - 1,400 ppm |
4-Aminoantipyrine | VACUettes | K-8012B | R-8012B | ||||||

Phenols | 0 - 1,000 ppm & 0 - 13,000 ppm |
4-Aminoantipyrine | VACUettes | K-8012C | R-8012C | ||||||

Phosphate (Ortho) | 0.0 - 1.0 & 1 - 10 ppm |
Stannous Chloride | CHEMets | K-8510 | R-8510 | ||||||

Phosphate (Ortho) | 0 - 30 ppm & 30 - 300 ppm |
Stannous Chloride | VACUettes | K-8510D | R-8510D | ||||||

Phosphate (Ortho) | 0 - 60 ppm & 60 - 600 ppm |
Stannous Chloride | VACUettes | K-8510A | R-8510A | ||||||

Phosphate (Ortho) | 0 - 120ppm & 120 - 1,200 ppm |
Stannous Chloride | VACUettes | K-8510B | R-8510B | ||||||

Phosphate (Ortho) | 0 - 1,200ppm & 1,200 - 12,000 ppm |
Stannous Chloride | VACUettes | K-8510C | R-8510C | ||||||

Phosphate (Ortho) | 10 - 150 ppm | Vanadomolybdo -phosphoric Acid |
CHEMets | K-8515 | R-8515 | ||||||

Phosphate (Ortho) | 2 - 30 ppm | Vanadomolybdo -phosphoric Acid |
CHEMets | K-8530 | R-8515 | ||||||

Silica | 0.0 - 1.0 ppm & 1 - 10 ppm |
Heteropoly Blue | CHEMets | K-9010 | R-9010 | ||||||

Silica | 0.00 - 0.20 ppm | Heteropoly Blue | ULR CHEMets | K-9011 | R-9011 | ||||||

Sodium Persulphate | See Persulphate | - | - | - | - | ||||||

Sulphide | 0.0 - 1.0 ppm & 1 - 10 ppm (as S) |
Methylene Blue | CHEMets | K-9510 | R-9510 | ||||||

Sulphide | 0 - 30 ppm & 30 - 300 ppm (as S) |
Methylene Blue | VACUettes | K-9510D | R-9510D | ||||||

Sulphide | 0 - 60 ppm & 60 - 600 ppm (as S) |
Methylene Blue | VACUettes | K-9510A | R-9510A | ||||||

Sulphide | 0 - 120 ppm & 120 - 1,200 ppm (as S) |
Methylene Blue | VACUettes | K-9510B | R-9510B | ||||||

Sulphide | 0 - 1,200 ppm & 1,200 - 12,000 ppm (S) |
Methylene Blue | VACUettes | K-9510C | R-9510C | ||||||

Sulphite (Free) | 2.0 - 20 ppm (as SO _{3}) |
Iodometric | Titrets | K-9602 | - | ||||||

Sulphite (Free) | 5.0 - 50 ppm (as SO _{3}) |
Iodometric | Titrets | K-9605 | - | ||||||

Sulphite (Free) | 10 - 100 ppm (as SO _{3}) |
Iodometric | Titrets | K-9610 | - | ||||||

Sulphite (Free) | 50 - 500 ppm (as SO _{3}) |
Iodometric | Titrets | K-9650 | - | ||||||

Sulphite in Wine* | 10 - 100 ppm (as SO _{2}) |
Ripper | Titrets | K-9610W | - | ||||||

Thiosulphate | 5.0 - 50 ppm | Iodometric | Titrets | K-9705 | - |

* = With exception of specialty test kit Sulphite in Wine, K-9610W, which comes in packs of 20 ampoules for convenience.

__Note:__ American English spellings: Persulphate (Persulfate), Sulphate (Sulfate), Sulphite (Sulfite) & Thiosulphate (Thiosulfate).

Site Map • Links • Terms of Use T: +44 (0) 1442 876817 © 2012-2017 Galgo (UK) Ltd
